Reliable, robust
and really real time

Truly real time data without
leaving your office?

It’s as simple as 1, 2, 3

1

Install smart sensors
(conXone’s and conXsensor’s)

Smart Sensors conXone and conXsensor​
2

Set up your pour

conx edge
3

Receive automated notifications or access conXedge to review and analyse pour

The multiple uses of conXedge

Smart Sensors conXone and conXsensor​
conXedge-icon-dk-tr

Column

conXedge-icon-dk-tr

Column

conXedge-icon-dk-tr

PT Slab

conXedge-icon-dk-tr

Vertical Wall

conXedge-icon-dk-tr

Column

conXedge-icon-dk-tr

PT Slab

conXedge-icon-dk-tr

Vertical Wall

Smart Sensors conXone and conXsensor​
conx edge
1

Smart Sensors conXone and conXsensor

- your data collectors
conxedge-sensor-node

conXone – these single use sensors are permanently embedded in the concrete and record and communicate the concrete temperature accurately and continuously in real time

conXsensor – these robust single channel sensors accurately and constantly record and communicate temperature data using consumable thermocouples or digital sensors in real time.

Once in place, your conXsensors and conXones can be left to get on with the job – so you can get on with yours.

Click here for technical specifications:
conXone conXsensor
Measurement Range -35°C to 100°C
(-31°F to 212°F)
-35°C to 100°C
(-31°F to 212°F)
Accuracy 0.5°C (0.9°F) 0.5°C (0.9°F)
Measurement Frequency 15 mins
(4 months of Data Storage)
15 mins
(4 months of Data Storage)
Wireless Range Up to 30 metres
(up to 98ft)
Up to 120 metres
(up to 390ft)
Sensor Lengths Surface, 1m (3.3ft), 3m (10ft) or Custom Surface, 1m (3.3ft), 3m (10ft) or Custom
Battery Life 4 months 6 months
(Replaceable AA Batteries)
Data Analysis conXedge Cloud Solution conXedge Cloud Solution
Standards Complies with ASTM C1074 Complies with ASTM C1074
2

conXagent or conXstation

- your data transmitter
Smart Sensors conXone and conXsensor​

This sophisticated 4 channel data logger, with wireless mobile technology, records and displays temperature information in REAL TIME, transferring it from the smart sensors to the conXedge cloud. If needed, conXagents can be daisy chained. Simply put, your conXagent is a data logger and a clever transmitter, sending a constant stream of data directly to the cloud and saving you or your team physically visiting the site to download the data from multiple on-site devices.

Technical specifications:
conXagent conXstation
Measurement Points 4 1
Measurement Range -35.0°C to 100.0°C
(-31°F to 212°F)
-35.0°C to 100.0°C
(-31°F to 212°F)
Accuracy 0.5°C (0.9°F) 0.5°C (0.9°F)
Measurement Frequency 5 mins
(4 months Data Storage)
5 mins
(4 months Data Storage)
Communication - Wireless Mobile Up to 120m
(Up to 390ft)
Up to 120m
(Up to 390ft)
Sensor Length Surface, 1m (3.3ft), 3m (10ft) or Custom Surface, 1m (3.3ft), 3m (10ft) or Custom
Battery Life Up to 4 weeks
(Rechargable)
Up to 4 weeks
(Rechargable)
Data Analysis conXedge Cloud Solution conXedge Cloud Solution
Standards Complies with ASTM C1074 Complies with ASTM C1074
3

conXedge

- your data manager
conx edge

Real time data is transferred continuously from the conXagents to the secure conXedge cloud system. The cloud system records and interprets the data using concrete maturity (Arrhenius or Nurse Saul) and/or mass concrete technology and

  • configures pours,
  • sets warning parameters,
  • sends out notifications and alerts using smart set and forget technology,
  • allows full analysis,
  • generates compliance reports,
  • provides complete traceability and auditability of all events and
  • securely stores historical data.
Think of it as your very own concrete analyst, alarm system and secure data storeroom – all in one – working 24/7.
Get the conXedge - your complete solution
for concrete thermal management.
